Feeding Material Part:
1. Single unwinder system,manual loader for unwind system
2. Automatic stop machine when break the material; When machine stop, keep tension and avoid the material loose or line deflection.
3. Air shaft
4. EPC (edge position control): With manually/automatically/ central return function, can adjust the rewind move left and right .
| Model | YTB |
| Type | Stack |
| Standard Machine width | 600mm 800mm 1000mm 1200mm |
| Material Feeding Width | 200-1600mm, also can customized for more width material |
| Printing Width | 160-1560mm, also can customized for more width material |
| Printing Length | Standard is 400mm，can customized from 300-1000mm |
| Max Machine Speed | 100 m/min |
| Printing Speed | 10-80 m/min Equip chamber doctor blade can reach 100m/min |
| Register precision | ≤0.3mm |
| Thickness of plate | 1.14mm 1.7mm 2.28mm 2.84mm 3.94mm can customized |
| Gear | 1.5mm |
| Transmission | Synchronous Belt |
| Heating | Electricity Heating |
| Double tape thickness for stick plate | 0.38mm 0.5mm can customized |
1. plate roller circumference: 300-1000mm, standard less than 400mm
2. print material: resin plate or rubber plate
3. Transmission between printing roller and anilox roller: Helical gears
4. printing chromatography: 360-degree rotation
5. adjustment method: By Manual (Automatic printing after adjust by manual, when start machine, no need register color again, the printing pressure and register all keep the same.)
6. Printing roller lifting system: pneumatic
Paper
Film
 |
 |
